- System Type : Modular Package
- Wastewater Type : Municipal
- Application : Residential
- Facility Description : Decentralized
- Permit Type : Surface Water Discharge
- Full Time Operators : 1
- Tight Nutrient Limits
- Streametric Remote Monitoring
SYSTEM HIGHLIGHTS
“We partnered with MMBR to be our technical support team for BluBox MBR systems. From design to factory testing. From commissioning, to operator training, and to ongoing support, the MMBR team has a ton of experience and a great attitude.”
—Integrated Water Services, Inc.
PROJECT OVERVIEW
| Project Type : | New Systems – Modular |
| Previous Facility Type : | N/A |
| Owner : | Available Upon Request |
| Current Engineer: | Available Upon Request |
| Contractor: | Integrated Water Services, Inc. |
| Operator : | Municipal Operations and Consulting |
| Delivery Method: | Design Build (DB) |
| Time to Build (Months) : | 8 |
PLANT DESIGN INFORMATION
| Fine Screen Type: | 2.0 mm Perforated Plate |
| Aeration Technology : | Fine Bubble |
| Air Scour Blower Type : | Regenerative |
| Solids Management : | Hauling |
| PLC/HMI Type: | AB/Factory Talk |
| Disinfection Method: | UV |
| # Process Stages: | 3 |
MEMBRANE ZONE DESIGN
| Filtration Mode: | Pumped |
| # of Reactors: | 4 |
| Membrane Type: | Microdyn Nadir® UF |
| Membrane Module Type: | BIO-CEL® |
| Design Flux (GFD): | 7.3 |
| Minimum Water Temperature (°C): | 12 |
| Peak Factor: | 2.0 |
